MODEL |
PH18-8048 PRO |
PH18-10048 PRO |
Nominal Battery System Voltage |
48VDC |
INVERTER OUTPUT |
Rated Power |
8000W |
10000W |
Surge Power |
16000W |
20000W |
Waveform |
Pure Sine Wave |
AC Voltage Regulation (Batt.Mode) |
230VAC±5% |
Output Frequency |
60Hz or 50Hz |
Inverter Efficiency(Peak) |
90% |
Transfer Time |
10ms (UPS) 20ms (APL) |
AC INPUT |
Nominal Input Voltage |
230VAC |
Max AC Input Voltage |
300VAC |
Selectable Voltage Range |
170~280VAC (UPS) / 90~280VAC (APL) / 184~253VAC(VDE4105) |
Frequency Range |
50Hz / 60Hz(Auto detection) |
SOLAR CHARGER & AC CHARGER |
AC Charging Current |
2-120A |
2-160A |
Maximum PV Array Open Circuit Voltage |
450VDC |
PV Array Open Circuit Voltage |
150-430VDC |
Cold Start Voltage |
46VDC |
Solar Charging Current |
80A/80A |
100A/100A |
Default Charging Current |
80A/80A |
Maximum Charge Current |
160A |
200A |
Charging Algorithm |
3-step (Flooded Battery / AGM / GEL/ LEAD Battery), 4-step(LI) |
MECHANICAL SPECIFICATIONS |
Machine Dimension (W*H*D) |
600*503*141.2mm |
G.W (kg) |
21kg |
OTHER |
Safety Certification |
CE |
Operating Temperature |
-10°C~50°C |
Storage Temperature |
-15°C ~60°C |
